OKSEA - MED 2000 - 2200 - 2300 /5.5

Hyperbaric Oxygen Chambers

Clinical Hyperbaric Oxygen Therapy Chambers

Our clinical hyperbaric chambers are all tailor-made. The production is made according to TUV, ACME, or BS. All The clinical hyperbaric chambers are a state of the art. WE can build many variants which can accommodate from 6 to 14 patients in the main chamber and 2 in the antechamber. The illumination is unique, the best in the market which gives 350 lux power light anywhere in the chamber. Communication and the climate control system are the most effective when compared to the others. Fire safety with the new adapted sensors is highly reliable and effective. The fire fighting system which is made according to EN 14931 or NFPA 99 truly tested after each installation up to the maximum working pressure before the chamber interior is finished. BIBS system is well-designed for the elderly to breathe easily under pressure.

  • Chambers with omega shape
  • All piping Equipment can be made from stainless steel compatible with oxygen
  • Computer control Option
  • Fire detection sensors
  • LED outside and if required inside the chamber
  • SP telephone
  • Effective silencers
  • Climate control system
  • Closed-circuit TV
  • Entertainment
  • Multi-gas selection during treatments
  • Oxygen, CO2 monitoring from the chamber's atmosphere
  • BIBS supply analyses
  • CO2 scrubbers
  • Medical Lock
  • Patient medical monitoring
  • Control from inside optional

OKSEATECH Therapy Rooms can be single locked or

twin locked, can operate at 2 bar or 5 bar operating pressure and can sit between 6 and 18 people. Treatment units for 16 + 2 people are also produced as double chambers.

 Therapy chambers can help treat various ailments and wounds, including diabetic conditions, open wounds, multiple sclerosis (MS), sporting injuries, burns and many more.

Chambers can be made to fit requirements with a variety of seating numbers, pressure ratings.

Accreditation and compliance to multiple industry standards including ISO/BSI, Lloyds Register, TUV and HSE guidelines.

Produced for ease of operation and high level of patient comfort.


Read More
  • Teknik Özellikler
  • Catalogs (1)

1.1. TECHNICAL SPECIFICATIONS

 Maximum working over-pressure 5,0 bar

Maximum design over-pressure 5.5 bar

Test over-pressure 8,25 bar

Material P355GH

 Main chamber capacity 10 + 1 persons

Ante chamber capacity 2 persons

Length of main chamber 5000 mm

Length of ante chamber 1000 mm

 Main chamber volume 16.750 I

Ante chamber volume 3.900 I

Length overall (incl. control station) 6000 mm

Width overall (incl. control station) 2250 mm

Height overall (incl. lamps) 2250 mm

Number of doors 3 e/a

Number of windows in MC 4 e/a

TV-windows 4 e/a

Number of windows in AC 2 e/a

TV-windows 2 e/a

Window-diameter free 300 mm

TV-windows 150 mm

Medical lock main chamber MC free diameter 250 mm free length 300 mm

Illumination cold LED lights with acrylics

Depth Gauges Accuracy Analog %0.25 Digital %0.05

SP Phone 3 e/a

Oxygen BIBS Masks 14 e/a

Communication System 2-way Intercom

Humidity and Temparature Indicators Digital

Connection load approx. 5000 Watt

Electrical connected voltage 220 / 380 50 Hz
